Screw Mount Full Bridge Strain Gauges Offering Insulation Resistance Equal or Above 5000 Mega Ohms 100VDC Designed for Mechanical Strain Sensing

Product Description:

The Strain Gauge Load Cell is a high-precision sensor designed to provide accurate and reliable measurements in various industrial and laboratory applications. Utilizing advanced Full Bridge Strain Gauges technology, this load cell ensures exceptional sensitivity and stability, making it ideal for tasks that require precise force measurement. The incorporation of Linear Strain Gauges within the design enhances the device's ability to detect minute changes in strain, delivering consistent and repeatable results under different load conditions.

One of the standout features of this Strain Gauge Load Cell is its impressive linearity of 0.2 %FS, which guarantees that the output signal remains proportional to the applied load throughout the entire measurement range. This high degree of linearity minimizes measurement errors and simplifies calibration processes, enabling users to achieve accurate data with confidence. Additionally, the load cell exhibits a very low hysteresis value of ≤0.02%F.S., meaning that the sensor returns to nearly the same output when the load is removed, further contributing to its reliability and precision.

Durability and electrical performance are also critical aspects of this strain gauge load cell. It boasts an insulation resistance of ≥5000 MΩ at 100VDC, which ensures excellent electrical isolation and reduces the risk of signal interference or leakage currents. This high insulation resistance is particularly beneficial in environments where stable and noise-free signal transmission is essential, such as in automated weighing systems and quality control equipment.

The compensated temperature range of -10℃ to 50℃ allows the load cell to maintain consistent performance across a broad spectrum of operating conditions. Temperature compensation is vital in maintaining the accuracy of strain gauges, as temperature fluctuations can cause drift and affect measurement stability. By compensating for these variations, the load cell delivers dependable results even in challenging environments where temperature changes are common.

Designed with both performance and versatility in mind, this strain gauge load cell is constructed to provide long-term stability and durability. The use of high-quality materials and precise manufacturing techniques ensures that the Full Bridge Strain Gauges and Linear Strain Gauges integrated into the device perform optimally over extended periods. This makes the load cell an excellent choice for applications such as force measurement in mechanical testing, industrial automation, robotics, and structural monitoring.

In summary, the Strain Gauge Load Cell combines high precision, excellent linearity, minimal hysteresis, and superior insulation resistance to deliver outstanding measurement performance. Its temperature compensation capabilities further enhance its reliability, making it suitable for a wide range of operating environments. Whether you require accurate force measurement for research, production, or quality assurance, this load cell equipped with advanced Strain Gauges technology offers a dependable solution that meets the highest standards of accuracy and durability.

Features:

• Product Name: Strain Gauge Load Cell
• Utilizes Foil Strain Gauges for high accuracy and reliability
• Incorporates Full Bridge Strain Gauges for enhanced sensitivity
• Temperature Effect On Zero: ≤0.02% F.S. / 10℃
• Insulation Resistance: ≥5000 MΩ (100VDC)
• Operating Temperature Range: -10℃ to 60℃
• Mounting Type: Screw Mount for secure installation
• Linearity: 0.2 % F.S. ensuring precise measurement

Technical Parameters:

Applications:

The Top Sensor CL-04 Strain Gauge Load Cell is an advanced measurement device designed for high precision and reliable performance in various industrial and commercial applications. Manufactured in China, this load cell utilizes high-quality Shear Strain Gauge technology, ensuring accurate force measurement with minimal temperature-induced errors. With a compensated temperature range of -10℃ to 50℃ and a temperature effect on zero of ≤0.02%F.S./10℃, it delivers consistent performance even in fluctuating environmental conditions.

This model is constructed from durable alloy steel or alloy aluminum, providing excellent strength and corrosion resistance. The screw mount design facilitates easy and stable installation in different setups. The CL-04 load cell is ideal for applications requiring precise strain measurement, such as material testing machines, industrial automation, robotics, and weighing systems. Its high precision and good performance make it suitable for both laboratory and production line environments where accurate force data is critical.

Strain gauges embedded within the CL-04 load cell are designed to detect minute deformations caused by applied loads. The shear strain gauge configuration enhances sensitivity and reduces signal noise, making it perfect for applications involving dynamic or fluctuating loads. Industries such as aerospace, automotive, and manufacturing greatly benefit from the reliable data provided by these strain gauges for quality control and structural health monitoring.

With a minimum order quantity of 20pcs, Top Sensor ensures a steady supply ability of 2000pcs per month, packaged securely in carton boxes and pallets for safe transportation. The delivery time ranges from 20 to 25 days, with payment terms requiring T.T in advance. This makes the CL-04 an accessible and efficient choice for businesses looking to integrate high-quality strain gauge load cells into their systems.

In summary, the Top Sensor CL-04 Strain Gauge Load Cell is perfectly suited for a wide range of application occasions and scenarios where precision strain measurement is essential. Whether in research laboratories, industrial weighing, or automated machinery, the combination of advanced shear strain gauge technology, robust material construction, and reliable mounting options positions this product as a top-tier solution in the strain gauges market.

FAQ:

Q1: What is the brand and model number of this strain gauge load cell?

A1: The strain gauge load cell is from the brand Top Sensor, and the model number is CL-04.

Q2: Where is the Top Sensor CL-04 load cell manufactured?

A2: The Top Sensor CL-04 load cell is made in China.

Q3: What is the minimum order quantity for the CL-04 strain gauge load cell?

A3: The minimum order quantity for the CL-04 load cell is 20 pieces.

Q4: How is the CL-04 load cell packaged for shipment?

A4: The CL-04 load cell is packaged in carton boxes and placed on pallets to ensure safe delivery.

Q5: What is the typical delivery time and payment terms for ordering the CL-04 load cell?

A5: The delivery time for the CL-04 load cell is typically 20-25 days, and payment is required via T.T in advance.

Q6: What is the monthly supply capacity for the Top Sensor CL-04 load cell?

A6: The supply ability for the CL-04 strain gauge load cell is 2000 pieces per month.
